Alarm System Planner
Houses with their lights on beneath Table Mountain at dusk, Cape Town

Free alarm planner for Cape Town

Plan your alarm system before you call an installer

Answer six quick questions. You get a plain-language list of the devices a typical system for your property would start with, and a checklist of questions to put to any installer.

  • Free
  • No sign-up
  • Nothing is sent unless you ask

Start the planner

Tell us about your property

Six questions. Your plan below updates as you answer.

1. What are you protecting?
2. How many outside doors?

Count garage, sliding and back doors.

3
3. How many ground-floor windows open?

Windows someone could reach from outside.

4
4. Do pets roam inside?
5. How many levels?
6. How long do power cuts usually last?

Load-shedding and other outages.

Your plan

A typical starting point for:

Devices in your plan

Alarm control panel

1

The brain of the system. Every sensor reports to it, and it decides when to sound the sirens and send the alert.

Ask which brand and model it is, and whether more sensors can be added later.

Keypads

2

One by the main entrance and one on the upper level, so you can arm or disarm without crossing the property.

Door contacts

3

A magnetic contact on each outside door tells the panel the moment it opens. Count garage, sliding and back doors too.

Motion detectors

About 3

Cover the passages and rooms someone would walk through. A typical starting point is one per level, plus one for every four ground-floor windows.

Window contacts or glass-break detectors

Up to 4

A contact on each window that opens reports when it is opened. A glass-break detector listens for breaking glass and can cover several windows in one room, so you may need fewer of them.

Ask which one the installer recommends for your windows, and why.

Sirens

1 inside, 1 outside

The inside siren wakes you and unsettles an intruder. The outside siren with a strobe tells neighbours and passers-by that this property is alarming.

Remote fobs with panic button

2

Arm and disarm from the car or the gate, and call for help from anywhere in the house. A panic signal helps most when a monitoring company is there to act on it.

GSM or internet communicator

1

Sends alerts to your phone and to a monitoring company. A cellular (GSM) link keeps working when a power cut takes your router or fibre line down.

Ask whether it works on the cellular network as well as your internet line.

Standby battery

1

Keeps the system running when mains power fails. Size it for the longest power cut you usually have, which you said is up to 4 hours.

Ask for a stated runtime that comfortably covers 4 hours with every device connected.

Features to ask for

Stay mode

Arms the doors, windows and ground-floor detectors while you sleep upstairs, so you can move about the upper level without setting it off.

Power-failure and low-battery alerts

The system tells you when mains power fails or the battery is low, so you know before the siren stops working.

Monitoring options

Three common ways an alarm can be answered. None is right for everyone, and each has different costs and contract terms, so ask for them in writing.

Siren only

The alarm sounds on site. Nobody is notified unless you or a neighbour hears it and acts.

No monitoring contract.

Phone alerts

You are alerted by call or app notification and decide what to do. Needs a communicator and a reliable cellular signal.

Ask whether the app or alerts cost extra.

Control-room monitoring with armed response

A control room is notified and sends a responder. This is usually a monthly contract.

Ask who responds, the response time in writing, the contract term and how to cancel.

This is a planning guide, not a quote, a security survey or professional advice. The quantities are a typical starting point. A site visit by a registered installer will change them.

Questions to ask any installer

Tick them off as you go, or print this page and take it with you. The list changes with your answers.

Print this plan

Keep a copy of your plan to take with you when you speak to an installer.

Promoted by WP Security, the publisher of this site

Happy with your plan?

If it looks right, WP Security, the Cape Town installer that publishes this site, offers a free on-site assessment. We send them your plan with your details, so you do not have to explain it again.

Not yet, change my answers

Prefer to talk? Call 087 808 3665 or WhatsApp

How your plan is worked out

The rules are simple and the same for everyone. They give a starting point to talk through with an installer, not a final design.

  • Every outside door gets a door contact.
  • Motion detectors: one per level, plus one for every four ground-floor windows, plus one for a stockroom or cash area in a business.
  • Ground-floor windows that open get a window contact or a glass-break detector.
  • A second keypad if there is an upper level.
  • Pets change the type of motion detector, not the number.
  • Battery advice follows how long your power cuts last.
  • Door contact
  • Motion detector and its coverage
  • Keypad
  • Outside siren and strobe

Illustration only. Every property is different.

Glossary

The terms you will hear from installers, in plain language.

Control panel

The central unit that receives signals from every sensor and triggers the sirens and alerts.

Keypad

Where you arm and disarm the system with a code.

Door contact

A two-part magnetic sensor that reports when a door is opened.

Motion detector (PIR)

Senses movement by the heat a person gives off. PIR stands for passive infrared.

Pet-tolerant detector

A motion detector set to ignore animals up to a stated weight.

Glass-break detector

Listens for the sound of breaking glass and can cover several windows in one room.

Siren and strobe

The loud sounder and flashing light that signal an alarm on the property.

Communicator (GSM or internet)

Sends alerts to your phone or a control room over the cellular network or your internet line.

Standby battery

Keeps the system running during a power cut.

Stay mode

Arms doors and windows while you are home, with the indoor detectors switched off.
